Press this button while a track is selected to assign it to Deck 1 in the software. Press this button twice to perform an "instant double", automatically loading the selected track on one deck to the opposite deck.
Filter/Low: Press and hold MODE/SHIFT and press LOAD 1 to change the function of the Filter/Low knob to control either the software Filter (default) or Low EQ.
Press this button while a track is selected to assign it to Deck 2 in the software. Press this button twice to perform an "instant double", automatically loading the selected track on one deck to the opposite deck.
Vinyl Mode: Press and hold MODE/SHIFT and press LOAD 2 to turn the vinyl mode on or off. When vinyl mode is On, use the platter/jog wheel to grab and move the audio, "scratching" the track as you would with a vinyl record. When vinyl mode is Off, use the platter/jog wheel to bend the pitch of the track.
This LED indicates Bluetooth pairing and connected status. The unit is always in pairing mode when not connected via USB and not already connected to a Bluetooth device.
Adjusts the amount of the filter effect. Turning the knob left and right will produce a low-pass filter and high-pass filter, respectively.
Low EQ: Press and hold MODE/SHIFT and press LOAD 1 to use this knob to adjust the Low EQ. Turning the knob left and right attenuates or boosts the bass frequencies, respectively.
Press this button to send this channel's pre-fader signal to the Cue Channel for monitoring. When engaged, the button will be lit. Press one PFL button at a time to cue that channel alone and deactivate PFL monitoring for the other channels.
This capacitive, touch-sensitive jog wheel controls the audio when the wheel is touched and moved. To bend the pitch of the track, grab the non-touch-sensitive outer wheel.
When the Deck is paused, set a Temporary Cue Point by moving the Platter to place the playhead at the desired location and then pressing the Cue button.
During playback, press the Cue button to return the track to this Temporary Cue Point. If a Temporary Cue Point was not set, then it will return to the beginning of the track.
Track Beginning: Press and hold MODE/SHIFT and press this button to return the current track to its beginning.
Load Previous Track: If the play head is at the start of the track, press and hold MODE/SHIFT and press this button to load the previous track from the current list.
Press this button to change the current function of the Performance Pads. Hold this button and press a pad to perform its SHIFT function.
Hot Cue: Each pad assigns at Hot Cue Point, or returns the track to that Hot Cue Point. When a pad is unlit, you can assign a Hot Cue Point by pressing it at the desired point in your track.
Delete Hot Cue: Press and hold MODE/SHIFT and press a pad to delete the hot cue.
Loops: Each pad triggers and auto-loop of a different length.
Effects: Each pad triggers a software effect for the current deck.
Samples: Each pad triggers a sample in your DJ software.
Stems:Each pad triggers a stem.
Shift: Press and hold this button to access SHIFT functions.
Press this button to activate the Fade FX feature in your DJ software.When Fade FX is active, moving the crossfader away from the current deck will apply the available Fade FX.
